Cooler DF1203812B2FN

The silent fan 12cm DC mining cooler is used to replace the damaged cooling fan of the miner Ebit and Avalon.

Model: DF1203812B2FN

Size: 120*120*38MM

Voltage: DC 12V

Current: 4.50A

Speed: 7000RPM

Air volume: 2870.38CFM

Wind pressure: 31.60mmH2O

Noise: 64dB-A

Bearing: High precision double ball bearing

Fan frame: one-shot injection molding, 30 glass fiber grade flame retardant

Fan blade: one-shot injection molding, 30 glass fiber grade flame retardant.

Fan rotation direction: counterclockwise when viewed from the direction of the fan blades

Operating Temperature: 10°C to 70°C

Storage temperature: 40℃ to 70℃

Power supply range: plus or minus 15 of the rated power supply

Insulation resistance: greater than 500 megohms

Withstand voltage: sink leakage current 0.5 5001 minutes

Working life: 80,000 hours at ambient temperature of 25 degrees
