The TPH1R204PL is a 10-pin semiconductor product transistor in an SOP-8 package.

Product features:

• High-speed switching

• Small gate charge: QSW= 17 nC (typ.)

• Small output charge: Qoss= 56 nC (typ.)

• Low drain-source on-resistance: RDS(ON)= 1.0 mΩ(typ.) (VGS= 10 V)

• Low leakage current: IDSS= 10 μA (max) (VDS= 40 V)

• Enhancement mode: Vth= 1.4 to 2.4 V (VDS= 10 V, ID= 0.5 mA)

• Package: SOP-8

• Minimum working temperature: - 55℃

• Maximum working temperature: + 175℃

• Dp - Power dissipation: 132 W
