SGM2036-1.2YN5G is a low power consumption, low dropout, CMOS linear voltage regulator on the s19j/s19j pro/s19a/s19 hyd/s19xp hash board of Antminer, which can work at 1.2V input voltage and provide up to 300mA Output current. They are perfect for low-voltage, low-power applications. It also provides low dropout to extend battery life in portable electronics. Features include a 10nA logic-controlled shutdown mode, short circuit current limit, and thermal shutdown protection. Operates in an ambient temperature range of -40°C to +85°C.

Feature:

• Low dropout voltage

• Thermal overload protection

• Built-in Foldback Protection Circuit

• 20µA Low Ground Current

• 10nA Logic-Controlled Shutdown

• 1.2V Input Voltage Range

• Short circuit automatic discharge function

• 300mA output current

• High output voltage accuracy

• Fast boot time

• -40°C to +85°C operating temperature range

Application:

• cell phone

• cordless phone

• PCMCIA card

• modem

• MP3 player

• handheld instruments

• Pocket PC

• Electronic planner

• Portable/battery-powered equipment

• s19j/s19j pro/s19a/s19 hyd/s19xp hash board
