CD4015BE

CD4015BE is 8 flip-flops plus input and output buffers. All register levels are D-type flip-flops. The logic level of the DATA input is transferred to the first register stage and shifted by one stage at each forward clock transition. All stages of resetting are completed by the high level on the RESET line.

Logic Family / Base Number: CD4015

Shift Register Function: Serial to Parallel

No. of Elements: 2 Element

No. of Bits Per Element: 4bit

Logic Case Style: DIP

No. of Pins: 16Pins

Supply Voltage Min: 3V

Supply Voltage Max: 18V

IC Output Type: CMOS

Logic IC Family: CD4000

Logic IC Base Number: 4015

Operating Temperature Min: -55°C

Operating Temperature Max: 125°C
